WS-C2960X-24TS-LL-NEW
Details
  • 24 x 10/100/1000 Ports - Gigabit Ethernet Switch
  • 2 x 1G SFP Uplinks
  • LAN Lite
  • Layer 2
  • Managed
Category
Stock

Additional information

Brand

Cisco

Cisco WS-C2960X-24TS-LL Switch for Small Businesses

Cisco WS-C2960X-24TS-LL Switch is designed for operational simplicity and to reduce the total cost of ownership. Cisco WS-C2960X-24TS-LL Switch is ideal for small businesses that want to implement a Catalyst network, as well as for larger operations that want no-frills units for secondary and tertiary roles.

Key Benefits of Cisco WS-C2960X-24TS-LL Switch

Cisco WS-C2960X-24TS-LL Switch optimizes routines to minimize maintenance needs, with automated power-reduction, packet-management, VoIP QOS, and security monitoring systems.

This switching system is a low-cost option to enable highly affordable network expansions or serve as a great starting place for your new Cisco Catalyst network.



Enclosure Type Rack-mountable - 1U
Feature Set LAN Lite
Uplink Interfaces 2 x 1G SFP
Ports 24 x Ethernet 10/100/1000 Gigabit ports
Forwarding Bandwidth 50Gbps
Switching Bandwidth 100Gbps
RAM 256 MB
Flash Memory 64 MB
Dimensions 44.5 cm x 27.9 cm x 4.5 cm
Package Weight 9.19 Kg
Network management Interface 10/100 Mbps Ethernet (RJ-45)
Available PoE Power None
Forwarding bandwidth(Gbps) 50Gbps
Maximum stacking number None
Stack Bandwidth None
Forwarding Performance 68.5Mpps
Switching bandwidth 100Gbps
Maximum active VLANs 64
MAC Address Table Size 16K (default)
CPU APM86392 600MHz dual core
RAM 256 MB
Flash Memory 64 MB
Status Indicators Per-port status: Link integrity, disabled, activity, speed, and full duplex System status: System, RPS, Stack link status, link duplex, PoE, and link speed
Console ports USB (Type-B), Ethernet (RJ-45)
Stacking cable None
Power Redundancy Option (PWR-RPS2300)
Voltage range (Auto) 110V-240V
Power Consumption Operational 0.035KVA
Width 17.5 Inches (44.5 cm)
Depth 11 Inches (27.9 cm)
Height 1.75 Inches (4.5 cm)
Package Weight 8.2 Pounds (9.19Kg)
Weight 20.26 Pounds (3.7Kg)
Rack Mounting Kit optional
MTBF in hours 622,350
Compliant Standards IEEE 802.1D Spanning Tree Protocol
 IEEE 802.1p CoS Prioritization
 IEEE 802.1Q VLAN
 IEEE 802.1s
 IEEE 802.1w
 IEEE 802.1X
 IEEE 802.1ab (LLDP)
 IEEE 802.3ad
 IEEE 802.3af and IEEE 802.3at
 IEEE 802.3ah (100BASE-X single/multimode fiber only)
 IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports
IEEE 802.3 10BASE-T
 IEEE 802.3u 100BASE-TX
 IEEE 802.3ab 1000BASE-T
 IEEE 802.3z 1000BASE-X
 RMON I and II standards
 SNMP v1, v2c, and v3
 IEEE 802.3az
 IEEE 802.1ax
System software IOS LAN Lite
license NERGY-MGT-100-K9, EW-DO-100-DE
features  Jumbo Frames

 VLANS

Voice Vlan

VTPv2

CDPv2

LLDP

 802.3ad LACP

 PVST/PVST+

 802.1W/802.1S

 Port Fast/Uplink Fast

 port CoS Trust and Override

 Scheduling

 Priority Queuing

 Configure CoS Priority Queues

 Weighted Tail Drop

 DSCP transparency

Network security   SSH, SSL and SCP

 RADIUS and TACACS+

 SNMPv3 crypto

 802.1x

 802.1x Accounting / MIB

 802.1x w/ port security

 802.1x w/Voice VLAN

 802.1x Guest VLAN

 802.1x VLAN assignment

 802.1x MAC-Auth Bypass

 BPDU/Root Guard

 Port Security

 Private VALN Edge

 Storm Control

 Block unknown unicast and multicast

 IGMP Snooping

 IGMP Filter/Throttle

Management and Troubleshooting  Auto-MDOX

TDR

 UDLD

 IP SLA Responder

 layer 2 / IP Traceroute

 SPAN

 RSPAN

 Express Setup

 Device Manager

 Cisco Network Assistant

 Smartports + Advisor

 Troubleshooting Advisor

 Drag-and-drop Cisco IOS Upgrade

 IP Address DHCP

 Autoinstall with saved configuration

 Configuration Replace

 DHCP Auto Image Upgrade

 DHCP Port Based Allocation

 Error Disable MIB

Operating temperature up to 5000 ft (1500 m) 23F to 113
Operating temperature up to 10,000 ft (3000 m) 23F to 104F
Short-term exception at sea level* 23F to 131F
Short-term exception up to 5000 feet (1500 m)* 23F to 122F
Short-term exception up to 10,000 feet (3000 m)* 23F to 113F
Short-term exception up to 13,000 feet (4000 m)* 23 to 104F
Storage temperature up to 15,000 feet (4573 m) -13 to 158F
Operating altitude Up to 10,000 feet
Storage altitude Up to 13,000 feet
Operating relative humidity 10% to 95% noncondensing
Storage relative humidity 10% to 95% noncondensing
