Give your office network a boost of speed and performance that takes almost no time to set up. Easily build a highly reliable network to connect your computers, printers, copiers, and other office equipment. If your business is like most small companies, you do not have an IT staff to set up your network for you. Now you can have a high-performance, business-class office network that just works, right out of the box, with the Cisco 110 Series Unmanaged Switches. Users, workgroups, labs, departments, or growing offices can now deliver large amounts of multimedia, image, and video information across the network in almost no time.
Cisco 110 Series Unmanaged Switches deliver basic network connectivity and reliability for small businesses that is easy on the budget and without all the complexity. These switches provide all of the features, expandability, and investment protection you expect from Cisco, with no installation software and nothing to configure. Just plug it in, connect your computers and other business equipment, and get to work.
| Device type |
Switch – 5 ports – unmanaged  |
| Enclosure type |
Desktop |
| Ports |
5 x 10/100 |
| Power over Ethernet (PoE) |
N/A |
| Performance |
Switching capacity: 1 Gbps    Forwarding performance (64-byte packet size) : 0.74 Mpps |
| MAC address table size |
1000 entries |
| Jumbo frame support |
N/A |
| Features |
Flow control, Layer 2 switching, auto-negotiation, auto-uplink (auto MDI/MDI-X), Weighted Round Robin (WRR) queuing, quality of service (QoS), cable diagnostics, loop detection, Energy Efficient Ethernet |
| Compliant standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3az, IEEE 802.1p, IEEE 802.3x |
| Status indicators |
Power, link/activity, cable diagnostics, loop detection |
| Interfaces |
5 x 10Base-T/100Base-TX – RJ-45 |
| Power device |
Power adapter – external |
| Voltage required |
DC 12 V |
| Electric current required |
500 mA (operating) |
| Width |
3.7 in |
| Depth |
3.6 in |
| Height |
1.1 in |
| Weight |
7.5 oz |
| Fanless |
Yes |
| Compliant standards |
UL 60950, FCC CFR47 Part 15, CSA 22.2 |
| Localization |
Chinese (simplified), German, French, Italian, Spanish, Japanese |
| OS required |
N/A |
| Min operating temperature |
32 F |
| Max operating temperature |
104 F |
| Humidity range operating |
10 – 90% (non-condensing) |
| Min storage temperature |
-4 F |
| Max storage temperature |
158 F |
| Humidity range storage |
10 – 90% (non-condensing) |
