Features
Content
QSFP-H40G-CU3M-NEW
Details
  • Direct-attach cable
  • QSFP+ to QSFP+
  • 10 ft
  • Twinaxial
  • orange
  • for Catalyst 3016; Nexus 3016
  • 3064-E
Category
Stock

Additional information

Brand

Cisco

Cisco QSFP+ to four SFP+ copper Direct-Attach Breakout Cable is suitable for very short distances and offers a highly cost-effective way to connect within racks and across adjacent racks. The breakout cable connects to a 40G QSFP+ port of a Cisco switch on one end and to four 10G SFP+ ports of a Cisco switch on the other end.
Description Cisco 40GBASE-CR4 QSFP direct-attach copper cable, 3-meter, passive
Dimensions 13.5 x 18.4 x 72.4 mm
Cable Type Direct-attach copper cable assembly
Cable Distance 3m
Power Consumption (W) 1.5
Pull Tab Color Orange
Commercial temperature 0 to 70C (32 to 158F)
Storage temperature -40 to 85C (-40 to 185F)
Standards GR-20-CORE: Generic Requirements for Optical Fiber and Optical Fiber Cable

GR-326-CORE: Generic Requirements for Single-Mode Optical Connectors and Jumper Assemblies

GR-1435-CORE: Generic Requirements for Multifiber Optical Connectors

IEEE 802.3ba (-SR4, -LR4)

IEEE 802.3ae (-CSR4)

QSFP+ MSA SFF-8436

SFP+ MSA SFF-8431 and -8461

RoHS 6

Safety Cable jacket of QSFP copper modules is UL E116441 Compliant

QSFP copper cables are ELV Compliant
